Noctigon/Thrower

Noctigon DM1.12

One body with two beams: a reflector thrower in the centre and a ring of twelve flood emitters around it, each on its own Anduril 2 channel, from a 21700 (a 26800 tube is a $20-plus option). The output figures Hank publishes are for the SBT90.2 centre emitter, a $49.95 upgrade over the $78.68 base price, and that is the configuration priced here: 4,500 lumens and 128,000 candela from the centre, about 716 metres; the base SFT-42R centre and the 3000K 95 CRI SFT-40 option carry no figures on the page. The ring takes NTG35 or 519A emitters at 95 CRI, or SST-20. It is 120 mm long with a 63 mm head, 174 grams, IP67, no charging, no stated runtime or warranty.

Beam profile

Thrower, about 12° wide. Reach first: a small hotspot that puts light a long way out.

Estimated from 4,500 lm ÷ 128,000 cd — how this works

The price shown is a snapshot from the last catalog sweep, not a live figure. Links to a brand's own store are not paid placements and earn us nothing.

Specifications

Output
4500lm
Peak intensity
128000cd
Beam distance
716m
Emitter
Luminus SBT90.2 + 12x Nichia NTG35
Colour rendering
70 CRI
Beam type
Throw
Cell
21700
Modes
Ramping + Stepped
Interface
Anduril 2
Water/dust
IP67
Dimensions
4.7 x 2.5 in
Weight
6.1 oz

Manufacturer figures, measured to ANSI FL1 where the brand states it.
